How to Fix Error B200 on Canon Printers

Canon Printer

Error B200 means the print head voltage or temperature is not normal. The Print head could be defective.... but first, try these solutions below:

Solution 1:

Disconnect the power cable from the printer.

Wait 1 hour.

Connect the power cable

Solution 2:

Check and Clean Head contact pin condition of the carriage unit

Check Cable connection especially the carriage FFC

Solution 3:

Turn off the power

Open the panel

Turn on the power

Wait for print carriage to start moving to the left.

Let it go past half way

Before print carriage reaches left hand side shut the cover.

Leave the Printer turned on

Solution 4:

Unplug the power cable.

Open the printer

Push the whole print head mechanic to the center

While the printer still open, plug the power and turn it ON.

When the printhead still moving and is going to the very LEFT, close the cover.

Wait until its boot up.

Solution 4a:

Take out all of the ink cartridges

Lift up the grey bar by where the ink goes

Left the print head in the middle of the printer all while the printer was off.

Solution 4b:

Clean the plastic head primers/cleaners themselves on the printer (the far right)

Solution 4c:

Turn off the printer

Open the cover

Turn on the printer

Wait for print carriage to start moving to the left and let it go past half way

Before print carriage reaches left hand side (but after going halfway across) shut the cover.

Leave the Printer turned on.

Solution 4d:

My Canon MX860 locked up with the B200 error when I continued printing without black ink. I removed printhead as described elsewhere and carefully flushed with hot tap water until no further ink waste was present. Reinstalled, but this did not resolve the B200 message and lockout.

Removed printhead again and this time removed 2 small screws (with jeweler's scredriver) on printhead to dimantle it. Use care to protect the ribbon cable. Do not try to remove this cable. You will see a complex rubber gasket. Remove this and clean with hot water. Set aside.

With screws removed, this will give access for more cleaning of the ink passages. Used hot water, then isopropal alcohol to wash, and finally a small (1/4") soft rubber tube to gently blow out water/alcohol from the printhead body. Be careful to not touch or push on the ink jets (little metal strips - large set for color; second set for black printing). Dried parts and reassembled. Carefully replace the gasket so that it fits over the plastic tips of the several ink ports.

Error B200 has disappeared

Ran printer maintenance from the PC: head deep cleaning, regular cleaning 3 times and head alignment check. Gradually print quality has been restored as ink has flowed into the printhead cavity and to the ink jets.

Solution 5:

Clean the printhead

Solution 5a:

Replace the Printhead

Solution 6:

Replace the power supply unit.

Solution 7:

Replace the logic board.
